7/64 (16mm²) 4-Core Full Gauge Industrial Copper Cable
Available Packaging Options & Wholesale Rate Sheet
Choose standard sealed coils or exact custom cuts per meter and foot
Complete standard 90-meter factory sealed coil (295.3 ft). Ideal for full house wiring circuits.
Custom cut length per meter (1m = 3.28 ft). Perfect for specific solar or machinery runs.
Sold per running foot. Buy exact custom footage with zero wastage.
Technical Specifications & Engineering Details
Cable Specifications
Applications & Performance
Heavy 3-Phase Industrial Power Transmission
Manufactured with 7 thick strands of 64 gauge pure copper per core, this cable is designed for heavy-duty commercial and industrial 3-phase distribution. It delivers stable power to high-torque machinery without phase imbalance or thermal degradation.
Recommended Applications
- Industrial Machinery: Plastic extrusion machines, flour mills, textile looms, and hydraulic presses.
- Agricultural Tube Wells: High-efficiency power cable for 25 HP to 40 HP submersible electric motors.
- Commercial Plazas & Multi-Tenant Buildings: 3-phase riser link feeding sub-distribution boards on each floor.
- Large Diesel Generators: Main transfer switch interconnect for 40 kVA to 60 kVA 3-phase generators.
Why Anwar Cables vs Retail Market Brands (GM, Fast, Eagle)?
100% electrolytic pure copper rods with full conductor gauge guarantee. Micrometer verification welcome at our Lahore Bilal Gunj factory. Save 20%–30% by buying directly from the manufacturer.
Frequently Asked Questions
Technical engineering and buying answers regarding this cable specification
The metric cross-section of 7/64 (16mm²) 4-Core Full Gauge Industrial Copper Cable is 6.0 mm², corresponding to the traditional Pakistani gauge of 7/44. It is constructed from 7 Strands × 0.044" (1.12 mm) Pure Copper adhering to full-gauge conductor standards.
This cable has a continuous safe current rating of 32 – 36 Amperes (Up to 8,000 Watts (220V)). It is engineered for Main Distribution Board feeds, 3kW – 6kW Solar Inverters, Heavy Kitchen Power, Sub-main distribution circuits and recommended for use with a 32A – 40A MCB Breaker.
Direct from Anwar Cables Bilal Gunj factory, this product is priced at Rs 800 ft (approx. Rs 2,624.7 per meter). Contact us via WhatsApp for instant volume quotes and nationwide cargo dispatch.
We use 100% oxygen-free electrolytic grade copper rods with zero scrap or alloy mixtures. We encourage electricians and contractors to verify individual strand thickness with a digital micrometer at our physical Lahore shop & factory.
3/29 (1.5mm²) is a lighter cable rated for 10–12 Amps, ideal for ceiling fans and lighting circuits. 7/29 (2.5mm²) has 7 conductors rated for 18–20 Amps, essential for 1.5-ton inverter air conditioners, instant geysers, and high-draw 16A power sockets.
